LD-100 Single Channel Vehicle Loop Detector for Parking Barrier Gates with 20-2000uH Inductance Range and Automatic Reset

Name: LD100 Single Channel Vehicle Loop Detector for Parking Barrier Gates with 202000uH Inductance Range and Automatic Reset
Brand: JUTAI
Price: 1 USD

MOQ : 1

Delivery Time : 3-5 working days after receipt the payment

Frequency : Four step switch selectable20-80KHz

Humidity : Up to 95% relative humidity without condensation

Certification : CE

Operation Temperature : -40℃ to +70℃ / (-111°F to +158°F)

Place of Origin : China

Power Supply : 110-240v

Model Number : LD-100

Self-turning Range : 20-2000μH

Payment Terms : T/T,L/C,D/A,D/P,Western Union,Paypal,Alipay

Relay : Presence relay / Fault relay

Frequency Selection : DIP Switch 9 & 10 (40K to 100KHz)

Price : Negotiable

Sensitivity : 6 way selectable/Highest0.010%DL/L/ Lowest 2.56%DL/L

Supply Ability : 10000pcs/month

Lightning Protection : 40000V

Visual Indications : Power LED - Red / Channel LED - Green

Brand Name : JUTAI

Response Times : Turn-on 10-90MS / Turn-off 10-90MS

Packaging Details : Carton Parcking(13.5*8.5*5cm)/0.3kg/unit

Reset Method : Reset by push button on front enclosure

Contact Now

LD-100 Parking Loop Detector with 20-2000uH Inductance Range and Automatic Reset

Product Overview

110-240V Single Channel Boom Barrier Loop Detector with 40000V Lightning Protection

LD-100 Single Channel Vehicle Loop Detector for Parking Barrier Gates with 20-2000uH Inductance Range and Automatic Reset

Product Description

The Parking Barrier Gate Loop Detector (LD-100) is a specialized sensor designed for parking barrier gates, enabling efficient identification and detection of all vehicle types including oversized vehicles, trucks, and motorcycles. This ensures reliable automatic gate opening and closing operations.

Key Advantages

Wide Sensing Range and High Sensitivity: Sensing range from 15 to 2000μH with high sensitivity for accurate detection of various vehicles
Automatic Reset Function: Automatically resets in case of malfunction, eliminating manual intervention and enhancing system reliability
Multiple Detection Level Selection: 16 selectable levels from 0.008% DL/L to 2.50% DL/L for flexible configuration
40000V Lightning Protection: Robust protection against lightning strike damage
Wide Operating Environment Range: Operates from -40°C to +70°C (-111°F to +158°F) for harsh weather conditions

Technical Specifications

Specification	Value
Self-tuning Range	20-2000μH
Sensitivity	16-way selectable / Highest 0.010% DL/L / Lowest 2.56% DL/L
Frequency	Four-step switch selectable 20-80KHz
Power Requirements	110-240VAC (48 to 62Hz)
Operation Temperature	-40℃ to +70℃ / (-111°F to +158°F)
Fault Output	Blinks slowly: may indicate short circuit or insufficient turns Blinks faster: may indicate open loop or excessive turns
Response Times	Turn-on 10-90MS / Turn-off 10-90MS
Visual Indications	Power LED - Red Channel LED - Green
Reset	Reset by push button on front enclosure
Relay Output	Presence relay / Fault relay
Humidity	Up to 95% relative humidity without condensation

DIP Switch Configuration

DIP 1 & 2 - Special Functions

DIP 3 & 4 - Relay B Output

DIP 5 - Automatic Reset

DIP 6, 7 & 8 - Relay A Delay

DIP 9 & 10 - Frequency Selection (40K to 100KHz)

Loop Installation

Quality Assurance & Manufacturing

Our production line ensures efficient mass production, rigorous quality control, and thorough pre-shipment testing to deliver loop detector products of the highest quality standards.

Certifications
